PET Woven Geotextile

PET Woven Geotextile is interwoven by high tenacity PET filament yarn into a dimensionally stable network. The fabric develops excellent frictional interaction with a wide variety of soil and granular materials.

Product Description

PET Woven Geotextile is interwoven by high tenacity PET filament yarn into a dimensionally stable network. The inherent characteristics of Polyester-high tensile strength and modulus,low elongation, low creep and high long-term design strength makes the good ideal for soil reinforcement application. The fabric develops excellent frictional interaction with a wide variety of soil and granular materials.

The relatively low openings of these fabrics enable them to act as efficient separators preventing the mixing of costly granular materials with fine-grained soils. It has reasonably high permeability to prevent excessive build-up of pore-pressures due to applied loadings.

Features of PET Woven Geotextile

Applications Of PET Woven Geotextile

PET Woven Geotextile Technical Data

Type Item No. Tensile Strength
(kN/m)
Elongation Width
MD CD (%) (m)
Bi-axial WG5050 50 50 13 1-5.2
WG8080 80 80 13 1-5.2
WG100100 100 100 13 1-5.2
WG200200 200 200 13 1-5.2
Uni-axial WG10050 100 50 13 1-5.2
WG20050 200 50 13 1-5.2
WG30050 300 50 13 1-5.2
WG500100 500 100 13 1-5.2
WG600100 600 100 13 1-5.2
WG800100 800 100 13 1-5.2
WG1000100 1000 100 13 1-5.2
