Polyester Geogrid
High strength Biaxial Polyester Geogrid is high tenacity multi-filament PET yarn knitting to the geogrids fabric with various mesh sizes, tensile strength from 20 to 1000kN/m for soil stabilization.
Product Description
High strength Biaxial Polyester Geogrid is high tenacity multi-filament PET yarn knitting to the geogrids fabric with various mesh sizes, tensile strength from 20 to 1000kN/m for soil stabilization.
Exterior of PET Geogrid coatedwith PVC or modified polymer mixture for UV, acid and alkali resistance prevents the bio-decomposition.
It’s a precision geogrids that offers superior junction strength and high coefficient of soil interaction for soil stabilization.
Features of Polyester Geogrid
- High tensile and long-term strength
- High tear strength
- Excellent creep resistance
- Flexible and durable
- Increased pull-out resistance and compound strength
- Optimum stability of the junction of the grid
- High chemical and biological resistance
- UV resistance / Cost effective
- High resistance to installation damage and ease of installation
Applications Of Polyester Geogrid
- Retaining retaining walls / steep slopes
- Landslide Repair
- Structural layers supporting road, railway and airport construction
- Soft soil stabilization
- Earth embankments over piles
Polyester Geogrid Technical Data
| Type | Item No. | Tensile Strength (kN/m) |
Elongation | Mesh Size | Width | |
|---|---|---|---|---|---|---|
| MD | CD | (%) | (mm*mm) | (m) | ||
| Bi-axial | PE2525 | 25 | 25 | 13 | 7-50 | 1-6 |
| PE5050 | 50 | 50 | 13 | 7-50 | 1-6 | |
| PE100100 | 100 | 100 | 13 | 7-50 | 1-6 | |
| Uni-axial | PE6030 | 60 | 30 | 13 | 12-50 | 1-6 |
| PE8030 | 80 | 30 | 13 | 12-50 | 1-6 | |
| PF10030 | 100 | 30 | 13 | 12-50 | 1-6 | |
| PF15030 | 150 | 30 | 13 | 12-50 | 1-6 | |
| PF20030 | 200 | 30 | 13 | 12-50 | 1-6 | |
| High Strength | PE200200 | 200 | 200 | 13 | 12-50 | 1-6 |
| PE400400 | 400 | 400 | 13 | 12-50 | 1-6 | |
| PE600600 | 600 | 600 | 13 | 12-50 | 1-6 | |
| PE600100 | 600 | 100 | 13 | 12-50 | 1-6 | |
| PE800100 | 800 | 100 | 13 | 12-50 | 1-6 | |
